CLOUD CHAMBER COLD PLATE TYPE BY NARIKA CORPORATION
- EN0035-01
This safe and affordable Cloud Chamber requires no dry ice or liquid nitrogen. Instead, the apparatus uses a specially designed cold plate that is capable of retaining a low temperature for about one hour by freezing the plate in a standard freezer. Tracks of radiation can be observed for about 20 minutes (until ethanol is vaporized) in a room at 25℃ (77°F). The cold plate can be used repeatedly by freezing it again. The only consumables required to observe radiation tracks are ethanol (99.5%) and hot water (~50° C). Detailed Instruction Guide included.
Thorium used in the source: The Isotope used is 232.
The activity of the source: specific activity (Bq/g) is 61-78, on average 71.3.
*life span of the source is 5+ years.
Our products are for use in a laboratory or educational setting only
use under appropriate supervision
